AC Tech VFD Drives

/in /by

Lenze Americas is the manufacturer of AC Tech VFD drives. AC Tech VFD drives are high-performance products used to optimize new and existing machinery for production. Lenze Americas is one of the leading drive and automation specialists in the field of machine engineering. Rapidly changing times present manufacturers with new and varied challenges. To succeed in the future, manufacturers will need to handle more extensive tasks in even shorter time frames; Lenze Americas aims to reachthis ideal.

SMV Series:The SMV series of AC TechVFD drives offer sophisticated auto-tuning and fast dynamic torque response. The SMV is designed for motor applications where dynamic speed and torque control is demanded. The SMV series isan attractive solution for a broad range of applications including: food processing machinery, packaging machinery, material handling, conveying systems, HVAC systems, and more.The SMV series uses an Electronic Programming Module (EPM) for programming. Maintenance techs can easily use the EPM to reconfigure drive parameters or reset the drive. When a drive reset is necessary on the SMV, customers can reset to factory default or preset settings within seconds. When SMV drives must be replaced, the parameter configuration can besaved by the user by simply plugging in the pre-programmed EPM.

MC1000 Series:The MC1000 Series of AC TechVFD drives are the intelligent, versatile and cost-effective choice for industrial applications. From harsh environments to high torque loads, the MC1000 Series drives meet the toughest requirements with reliability, at a low cost. Customers can easily program the MC1000 Series and integrate extensive I/O with an array of programmable functions. The MC1000 is available in power ranges of 1/4 to 150 HP. The MC1000 offersEnhanced Torque System (ETS). ETS allows maximum starting and accelerating torque and tight speed regulation, even under fluctuating load conditions. MC1000 drives feature manual boost for high starting torque, and auto-boost for high torque acceleration at any speed. The MC1000 features power-up & auto restart modes, sleep mode with adjustable speed threshold and time.The MC1000 also offers anoptional Form C Relay and Dynamic Braking.

MC3000 Series
The MC3000 series of AC TechVFD drives are for process control demands with fast acceleration and response. The MC3000 is rated for constant torque applications but can easily be configured for variable torque applications. Most Process Control drives are designed for variable torque applications where the motor is driving a centrifugal fan or pump. As such, these drives are limited to 110% current for overload situations such as acceleration or responding to a feedback change. The MC3000 is a true Constant Torque drive rated for 180% of rated current for 30 seconds and 150% for one minute. This allows faster response to system changes and the ability to apply the MC3000 to non-centrifugal applications such as compressors, conveyors and other constant torque loads. The MC3000 is available in the same power ranges and voltages as the MC1000.

MCH Series:The MCH series of AC TechVFD drives are manufacturedfrom 1 to 250 HP. Lenze engineers designed theMCH series for the HVAC market and specific requirements of industrial installations. Lenze engineers designed the MCH to operate standard induction motors. MCH series offer simple programming and operation control for maintenance technicians.Technicians use included drive software toadjust the motor to maintain a preset pressure, flow, temperature or other variables using PID setpoint control.The MCH Series include UL and cUL approved motor protection for single motor applications. The MCH Series is used in systems seen in applications such as fans, pumps and cooling towers.

To learn more about AC TechVFD drives, visit the Lenze Website. For AC TechVFD Drives Repair or Replacement quotes, contact Precision Electric.
