Cutler Hammer VFD

/in /by

Cutler Hammer VFD drives can reduceenergy consumption from 10 to 50 percent by adjusting the speed of its corresponding electric motor to its needed output. Cutler Hammer VFD drivesallows for steady speed error, fast torque rise time, high immunity to resonance vibrations and high starting torque and current. Cutler Hammer VFD drives can be customized to fitmultiple motor drive systems and high-speed applications. Cutler Hammer VFD drivescan be designed specifically for high-performance applications withhigh processing power, and the ability to use information from an encoder or resolver to provide precise motor feedback control. Cutler Hammer VFD drives also offer a uniquemicroprocessor to provide high dynamic performance for applications where precisemotor handling and reliability are required.

The Cutler Hammer DG1 General-Purpose drives are part of the Eaton next-generation PowerXL series of variable frequency drives specifically engineered for todays more demanding commercial and industrial applications.Cutler Hammer DG1 General-Purpose drives offeran industry-leading energy efficiency algorithm, high short-circuit current rating and robust design, safety and reliability. Cutler Hammer LCX9000 drives are liquid-cooled products that utilize potable water or a water-glycol mixture as a cooling medium. The LCX9000 has a compact size and low heat transfer rates to allow the enclosure size to be greatly reduced, which is especially beneficial in UL Type 4X applications.

Cutler Hammer PowerXL Enclosed Drivesare a next generation enclosed drive platform that packages Cutler Hammer’sPowerXL DG1 and SVX drive families in a fast and reliable design solution. Cutler Hammer CFX9000 Clean Power Drivesuse tuned passive filters to significantly reduce line harmonics at the drive input terminals. These drives are an excellent choice for small and midsize applications where harmonics are a concern. Cutler Hammer VFDCPX9000 Clean Power Drivesare used for water, waste water, HVAC, industrial and process industries where harmonics are present. They offer one of the purest sinusoidal waveforms available.

Cutler HammerMVX9000 Micro Drivesare sensorless vector variable frequency drives are designed to provide adjustable speed control of three-phase motors. EatonSLX9000 General Purposedrives are compact, yet powerful drive is based on the more robust SVX9000. It is designed to be the next generation of drives specifically engineered for modern commercial and light industrial applications.

Obsolete Cutler Hammer VFD Drives

The HVX series of Cutler Hammer VFD drives are obsolete. The HVX series of Cutler Hammer VFD drives are currently replaced by Cutler Hammer VFDEaton H-MAX drives.The HMAX series of HVAC frequency drives are designed to the HVAC market for fan, pump, and fluid control applications. The patented energy savings algorithm, high short-circuit current rating and intuitive user interface provide customers an energy efficient, safe, and easy to use solution for adjustable frequency drive needs.The H-MAX drive supports the increasing demand for energy savings in buildings, systems and facilities. Built in capabilities and unique features provide a competitive solution that can add value to any end user.

The MVX9000 series of Cutler Hammer VFD drives are obsolete and replaced by Cutler Hammer VFDEaton M-MAX drives.The M-Max Drive is a compact micro drive with a broad power range. The M-Max series of Cutler Hammer VFD HVAC frequency drives feature board coating, unique mounting characteristics, simple programming, and 50C Rating to makethe M-Max perfectly suited for machinery applications in many industries. Typical applications for the M-Max drives include Food and Beverage, HVAC, Packaging, Pumping, Textile, OEM, and more.

For Cutler Hammer VFD Repair and Replacement quotes, Contact Precision Electric.
