Baldor 100HP, 1785-2680RPM, 3PH, 60-90HZ, 405T FRAME - IDVSM4400T-4
Baldor 100HP, 1785-2680RPM, 3PH, 60-90HZ, 405T FRAME - IDVSM4400T-4 - Image 2
On Sale
Sale!
%
Off
8
Save $1,887
1887$
8%
1887
$
NEW, FACTORY SEALED!

Baldor 100HP, 1785-2680RPM, 3PH, 60-90HZ, 405T FRAME – IDVSM4400T-4

Discount
-8% $ 22780 22 List: $24667.00

In Stock

Quantity: 1
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50

Need Member, Reseller, or OEM Pricing?

Estimated Repair Price: $6,834.07 - $15,946.15

Request a Repair Quote

Product Specifications

Model #IDVSM4400T-4
Horsepower100.0 HP
Input Voltage(s):400 - 480 VAC Input,
RPM:1800
Rated Current:112 Amps @ 400 - 480 VAC Input
Frame:405T
Height21.28 in
Width30.85 in
Depth38.04 in
Weight1218 lbs
Learn MoreYou can hover your mouse over highlighted product specs to learn more.

Description

CAT NO IDVSM4400T-4 SPEC NO. P40G3932
SER.NO. FRAME 405T
HP RPM VOLTS AMPS HZ TYPE P
BASE 100 1785 460 115 60 SF 1.00
MAX 100 2680 460 112. 90 INSUL.CLASS F
DRIVE END BEARING 80BC03J30X CONSTANT TORQUE DUTY CONT AMB 40
OPP D.E. BEARING 80BC03J30X 1000:1 ENCL TEFC PHASE 3
DESIGN NO. A40WG0296-R002 FLUX AMPS 37.8 VPWM INVERTER READY
MAX SPEED/RPM 3600 OVERTEMP PROT 2 WK2 26.07 POLES 4 WEIGHT
000613007HV
