Description
Baldor-Reliance DC Control, DC SCR CONTROL, 115/230V, 1/50-2 HP, NEMA 4X
Features:
- Full wave SCR control with free wheeling diode (NEMA type K)
- Field power supply allows use with shunt wound DC motors as well as permanent magnet motors
- Adjustable accel, decel, current limit, IR comp, min and max speed
- Current limit indicating LED
- 5K speed pot for speed control
- Anti-demag circuit protects PM motors and helps protect the SCR power bridge against direct shorts
- Noise rejection circuit eliminates false starts and blown SCR’s
- UL and cUL recognized
Typical Applications:
Conveyors, mixers, packaging machinery and other applications requiring variable speed and constant torque.
Documents are in PDF format
Product Specifications
-
- BRANDBaldor-Reliance
- MANUFACTURERS PART NUMBERBC154
- DEPTH INCHES5
- NUMBER OF AXIS1
- HI-RES ANALOG INPUTN/A
- SPECIFICATION NUMBER–
- HP2
- AMBIENT TEMPERATURE MAX40
- ISOLATED INPUTOptional
- OPERATOR INTERFACEPOT
- CSA APPROVALApproved
- RS422/RS485N/A
- ENCLOSURE MATERIALNEMA 4X
- RESOLVER INPUTN/A
- WIDTH INCHES5.9
- CUL APROVALApproved
- RS232N/A
- COOLING TYPECONVECTION
- DC TACH INTERFACEN/A
- TYPEANALOG
- ISOLATED ENCODERN/A
- PNEUMATIC-IN/RELAY-OUTN/A
- INPUT VOLTAGE115/230
- HEIGHT INCHES9.5
- AMBIENT TEMPERATURE MIN0
- ULApproved
- INPUT PHASE – RATED1
- MASTER/PULSE/FOLLOWERN/A
- DYNAMIC/REGENERATIVE BRAKINGNONE
- CE APPROVALApproved
- FIELD POWER SUPPLYN/A
