Description
____________________________________________________________________________________________________________________________
Mains voltage 400 V AC
Rated power 4.7 kW
Rated speed 4050 r/min
Rated torque 11 Nm
Rated voltage 300 V
Rated frequency 270 Hz
Output current 10,2 A
Power factor 0.99
Motor mass inertia 13.853 kgcm2
Enclosure IP54
Temperature class F
Motor design B5A160 (FF130)
Motor shaft dxl 19×40 with featherkey
Electr. connection – power Plug
Electr. connection – feedback Plug
Electr. connection cooling Without
Motor protection KTY83 + PTC
Feedback safety system not acc. to IEC 61800-5-2
Feedback Resolver RS0
Cooling Self-ventilated
Brake version Permanent magnet brake
Brake voltage 24 V DC
Braking torque 19 Nm
Colour RAL 9005 = Jet black dull
Surface/corrosion protection OKS-G (primed)
Approval CSAUL
Commodity Code 85015240
Weight / unit 15.000 KG / 33.069 LB
The delivery time is approximately 15 working days
