Description
| Brand | Marathon |
| Product Type | Motor |
| Product Category | Explosion Proof |
| Product Class | Three Phase, TEFC Explosion Proof Motor |
| UPC Number | 722856204622 |
| Country of Origin | Mexico |
| Electrical Type | Three Phase |
| Phase | Three |
| Frame | None215T |
| HP | 10 |
| Kilowatts | 7.5 |
| Speeds | 1 |
| Enclosure | EPFC |
| Voltage | 230/460 |
| RPM | 1762 |
| Amperage | 25.0/12.5 |
| Rotation | Reversible |
| Material | Cast Iron |
| Power Factor | 81.3 |
| Frequency(hz) | 60 |
| Overload Protector | Thermostat |
| Efficiency | 91.7 |
| Service Factor | 1.15 |
| Width (in) | 20.00 |
| Length (in) | 26.00 |
| Height (in) | 18.00 |
| Weight (lbs) | 258.00 |
- Ambient (Celsius): 40°C
- Duty: Continuous
- Hazardous Location: DIV 1 EXP PROOF CL I GR CD CL II GR FG T3B
- Insulation Class: F
- IP Code: 54
- KVA Code: H
- Poles: 4
Explosion Proof Division 1 Class I, Groups C & D, Class II, Groups F & G Meets temperature code T3B,
Blue Chip Series quality, 100% cast iron construction for rigidity and reduced vibration
1.15 Service Factor on sinewave or 1.0 Service Factor on IGBT power
Precision balanced to .08/sec, Extended grease tubes
Normally closed thermostats (must be connected to control circuit)
Shaft slinger
UL Recognized, CSA Certified, and CE Mark
