TechTop GR3-CI-TF-284TSC-2-BR-D-25

Discount

-34% $ 1653 07 List: ~~$2518.00~~

CALL OR EMAIL US TO CHECK AVAILABILITY.

Need Member, Reseller, or OEM Pricing?

Estimated Repair Price: $680.00+ (Our Minimum)

Request a Repair Quote

Product Specifications

Model #	GR3-CI-TF-284TSC-2-BR-D-25
Height	16 in
Width	16 in
Depth	28 in
Weight	350 lbs
Learn More	You can hover your mouse over highlighted product specs to learn more.

Description

ELECTRICAL DATA
60 Hz 50 Hz
Horsepower 25.0 25.0
Speed, RPM 3550 2930
Voltage 230/460 190/380
# Phase 3
Full Load Amps 60.06/30.03 68.4/34.2
Power Factor 0.89 0.9
Nominal Efficiency 91.7 89.0
Service Factor 1.25 1.25
KVA Code M F

GENERAL DATA
Frame Size 284TSC
Frame Enclosure TEFC
Mounting Rigid/C-Flange
Insulation Class F
Duty Cont. / S1
NEMA Design A
Frame Material Cast Iron
Ingress Protection 55
Tropicalization true
Cable Entry 1-NPT 1-1/2″
Feet Removable 1
Double Drilled 0
Paint Color Graphite Gray
Paint RAL 7024
Weight lb 353.9025
