Description
The intelligent, versatile and cost-effective choice for industrial applications. From harsh environments to high torque loads, the M3000 Series microdrives meet the toughest requirements with outstanding reliability, at a low cost. The easy-to-program M3000 offers full features, extensive I/O, and a full array of programmable functions.
The M3000 is available in a power range of 1/4 to 150 HP (0.18 - 110 kW) and voltages ranging from 115 to 575 VAC. With its Enhanced Torque System (ETS), a highly efficient sine coding algorithm and auto-voltage boost, the M3000 delivers maximum starting and accelerating torque and tight speed regulation, even under fluctuating load conditions. A built-in, UL-approved thermal overload provides full motor protection.
The MC Series drives are built in rugged steel enclosures that hold up to daily life on the factory floor. The easy to read 16 character LCD display above the drive keypad allows for easy and intuitive set up as well as daily operation.
- 1/4 through 150HP (0.18 - 110kW)
- Input voltages from 120V single phase (with voltage doubler) to 590VAC
- NEMA Type 1, 12, 4 and 4X Enclosures
This constant horsepower drive can be set up for simple applications requiring ramped start, ramped stop and speed control to demanding applications that require PID set-point control and many other functions. The MC Series consists of the MC1000 and MC3000 models; most applications will use the MC1000 with a keypad that includes Start, Stop, up, down, forward/reverse, Program/Run, Auto/Manual and Enter buttons.
For non-reversing applications that require independent switching of start and stop from local to remote and speed control from auto to manual, the MC3000 series keypad replaces the forward/reverse button with Local/Remote.
Technical documentation for the MC Series Drive, and all AC Tech brand drives, is available in our Technical Library.
Superior Drive Performance:
M3450C - Modes Of Operation:
- V / Hz Speed Control (Constant or Variable)
- Torque Control (Constant or Variable)
M3450C - Performance Features:
- Manual boost for high starting torque
- Auto-boost for high torque acceleration at any speed
- Power-up and auto restart modes
- Sleep mode with adjustable speed threshold and time.
- Adjustable units display
- Slip compensation for tight speed regulation even under fluctuating loads
- Control configuration: local, remote, both, serial communications
- Auxiliary outputs - two open collector outputs and a Form C relay.
M3450C - Control Terminals:
- Digital Inputs (Active low, NPN)
- 1 Dedicated Stop
- 1 Dedicated Start
- 4 Programmable
- Digital Outputs:
- 2 Open Collector (NPN)
- 1 Form C Relay
- Analog Inputs:
- 1 voltage (0 - 10 VDC)
- 1 current (4 - 20 mA)
- Analog Outputs :
- 2 Outputs (0 - 10 VDC, 2 - 10 VDC can be converted to 4 - 20mA) proportional to speed and load
- Serial Communications:
- 2-Wire RS-485 Modbus RTU protocol for programming, monitoring and controlling
- Other:
- Speed Potentiometer Power Supply
- Signal Common
M3450C - Technical Specifications:
- Output wave form High carrier frequency, sine coded,pulse width modulated (PWM)
- Input voltage ratings 240/120,240/200, 480/400,590/480 VAC
- Input voltage tolerance 10%,-15% of rating
- Input frequency tolerance 48 to 62 Hz
- Output frequency 0-650 Hz
- Carrier frequency 2.5 kHz to 14 kHz (Drive rated at 8 kHz)
- Frequency stability 0.00006% / °C
- Overload current capacity 180% for 30 seconds, 150% for one minute (at 8 kHz)
- Service factor 1.0
- Power factor Near unity
- Efficiency Up to 98.5%
- Speed reference follower 0-10 VDC or 4-20 mA
- Control voltage 15 VDC
- Analog outputs 0-10 VDC,or 2-10 VDC (4-20 mA with 500 ohm total impedance). Proportional to speed and load
- Digital outputs Form C relay: 2A at 28 VDC or 120 VAC
- Two open-collector outputs: 40mA at 30 VDC
- Serial communications RS485 networkable, Modbus RTU (standard)
- Storage temperature -20° to 70° C
- Chassis -10°– 55°C
- Type 1 (IP31) -10°– 50°C
- Type 4 (IP65) -10°– 40°C
- Type 12 (IP54) -10°– 40°C
- Ambient humidity Less than 95%, (non‑condensing)
- Maximum altitude 3300 Feet (1000 meters) w/o derating
- Standards UL, cUL, CE(LVD)
- Warranty 2 Years
M3450C - Popular Applications Include:
- Food Processing Machinery
- Packaging Machinery
- Material Handling Systems
- Conveyor Systems
- Pump Systems
- Fan Systems
- Milling Machines
- Hydraulic Systems
- HVAC Systems
- ... And many others!
M3450C - Global Standards:
- UL (North America)
- cUL (Canada)
- CE Low Voltage Directive (EN61800-5-1) (Europe)
M3450C - Environment:
- -20 to 70 degrees celsius storage temperature
- Type 1 (IP31) -10 – 50 degrees Celsius operating temperature
- Type 4 (IP65) -10 – 40 degrees Celsius operating temperature
- Type 12 (IP54) -10 – 40 degrees Celsius operating temperature
- Ambient humidity: Less than 95%, (non‑condensing)
- Maximum altitude: 3300 Feet (1000 meters) without derating
The M3000 Series has a keypad with a Local / Remote key and software geared toward HVAC and other process control applications.
