Baldor has a wide selection of high performance AC brushless servo motors, DC servo motors and stainless steel servo motors for the motion control industry. Baldor has been leading the way in energy efficient industrial motors since the 1920’s has been supplying the industry with adjustable speed controls since 1952, and has been supplying servo and motion control since 1983.
Baldor goes beyond the industry standard with innovations to provide reliable performance, while exceeding customer expectations. Some examples of Baldor firsts:
- stocking of servomotors for with immediate delivery – Baldor’s commitment to provide service
- extra high insulated stator design for protection Baldor’s commitment to provide quality products
- superior bearings with improved Exxon PolyrexEM polyurea grease to provide 4 times greater life
- high temperature 200C moisture resistance, multi-coated copper wire to cope with large current spikes
Whether that means a product from stock, or a specific custom application, Baldor believes in providing customers with choices and is always ready to tackle the most challenging application.
Baldor’s AC brushless servo motors BSM N-series provide industrial motion control applications with low inertia to attain the highest acceleration capability – to allow you to position rapidly. The BSM N-series is used in the world’s fastest machines and demanding applications.
The N-Series brushless servo motors provide a rugged, durable design with high energy Neodymium-Iron-Boron magnetics. This series provides continuous stall torque capability ranging from 3.9 Lb-In (0.45 N-m) to 354 Lb-In (40 N-m). Peak torque capability is nominally 4 times continuous. This series has the lowest inertia to provide the maximum torque per package size.The BSM motor has been time proven over the years.
The BSM N-series is used in the world’s fastest machines, in industrial motion control applications such as: indexers, form/fill/seal, flying shears, cut-to-length, robotics, insertion, packaging, capping machines, laser trimming, marking/labeling and many other demanding applications.
The BSM C-series from Baldor provides industrial motion control machines with an AC brushless servo motor with higher inertia thus providing an excellent match for equipment requiring higher inertial matching. The goal of this series design was to increase torque while reducing package size (comparing to previous Baldor series). The result was a torque increase of up to 50% in some models, with a package reduction of up to 2 inches/50mm.
The BSM C-series provides continuous stall torques ranging from 10 Lb-In (1.2 N-m) to 1062 Lb-In (120 N-m). Peak torques are 3 times continuous. The C-Series provides an economical package best used in applications with higher load inertias.
The rotor is a time proven quality design the reliability has been proven in numerous worldwide applications. The BSM C-series is used in equipment such as: moving webs, machine tool, packaging, factory automation, material handling, printing converting, food packaging, assembly lines, and many other demanding applications.
To learn more about Baldor servo motors, visit the Baldor Website.
