400 HP Hitachi SJ700 Series Open Chassis Enclosed Variable Frequency Drive | 400 - 480 VAC 3 Phase Input | 480 VAC 3 Phase Output | 800.0 Amps | SJ700-4000HFU2
400 HP Hitachi SJ700 Series Open Chassis Enclosed Variable Frequency Drive | 400 - 480 VAC 3 Phase Input | 480 VAC 3 Phase Output | 800.0 Amps | SJ700-4000HFU2 - Image 2
400 HP Hitachi SJ700 Series Open Chassis Enclosed Variable Frequency Drive | 400 - 480 VAC 3 Phase Input | 480 VAC 3 Phase Output | 800.0 Amps | SJ700-4000HFU2 - Image 3
400 HP Hitachi SJ700 Series Open Chassis Enclosed Variable Frequency Drive | 400 - 480 VAC 3 Phase Input | 480 VAC 3 Phase Output | 800.0 Amps | SJ700-4000HFU2 - Image 4
400 HP Hitachi SJ700 Series Open Chassis Enclosed Variable Frequency Drive | 400 - 480 VAC 3 Phase Input | 480 VAC 3 Phase Output | 800.0 Amps | SJ700-4000HFU2 - Image 5
400 HP Hitachi SJ700 Series Open Chassis Enclosed Variable Frequency Drive | 400 - 480 VAC 3 Phase Input | 480 VAC 3 Phase Output | 800.0 Amps | SJ700-4000HFU2 - Image 6
400 HP Hitachi SJ700 Series Open Chassis Enclosed Variable Frequency Drive | 400 - 480 VAC 3 Phase Input | 480 VAC 3 Phase Output | 800.0 Amps | SJ700-4000HFU2 - Image 7
400 HP Hitachi SJ700 Series Open Chassis Enclosed Variable Frequency Drive | 400 - 480 VAC 3 Phase Input | 480 VAC 3 Phase Output | 800.0 Amps | SJ700-4000HFU2 - Image 8
400 HP Hitachi SJ700 Series Open Chassis Enclosed Variable Frequency Drive | 400 - 480 VAC 3 Phase Input | 480 VAC 3 Phase Output | 800.0 Amps | SJ700-4000HFU2 - Image 9
400 HP Hitachi SJ700 Series Open Chassis Enclosed Variable Frequency Drive | 400 - 480 VAC 3 Phase Input | 480 VAC 3 Phase Output | 800.0 Amps | SJ700-4000HFU2 - Image 10
NEW, FACTORY SEALED!

Prices Include:

  • FREE Ground Shipping On Drives And Softstarters

    Storewide On All Drives And Softstarters Over $350*

  • Unlimited US Based Phone Support

    Contact Us Any Time At 1-574-256-1000.

  • Access To Our Team Of Engineers

    Trust Our Over 100 Years Combined Industry Experience

  • American Small Business

    Family Owned And Operated Customer Service Since 1983.

  • Hassle Free Warranty Claims

    We Help Process Warranty Replacement & Repair Claims.

400 HP Hitachi SJ700 Series Open Chassis Enclosed Variable Frequency Drive | 400 – 480 VAC 3 Phase Input | 480 VAC 3 Phase Output | 800.0 Amps | SJ700-4000HFU2

OBSOLETE PRODUCT. TO PREVENT DOWNTIME, WE STRONGLY ADVISE CONTACTING US FOR REPAIR OR ALTERNATIVES.

Send Enquiry for 400 HP Hitachi SJ700 Series Open Chassis Enclosed Variable Frequency Drive | 400 – 480 VAC 3 Phase Input | 480 VAC 3 Phase Output | 800.0 Amps | SJ700-4000HFU2

Unauthorized enquiry
Enquiry email sent successfully!

Call or Email Us for an Estimated Repair Price.

Request a Repair Quote
  • Specifications
  • Overview
  • Manuals

Product Specifications

ManufacturerHitachi
SeriesSJ700 Series
Model #SJ700-4000HFU2
Warranty:18 Month Manufacturer
Horsepower400.0 HP
Input Voltage(s):400 - 480 VAC Input,
Output Voltage(s):480 VAC Output
Rated Current:800.0 Amps
Input Phase:Three Phase Input
Output Phase:Three Phase Output
Phase ConverterNo
Enclosure:Not Rated
UV RatingNone
Height51 in
Width27 in
Depth18 in
Weight210 lbs
Operating ModesSensor (Closed Loop) Vector Control (Requires Feedback Module), Sensorless (Open Loop) Vector Control, Speed Control (V / Hz), Torque Control (Constant), Torque Control (Variable)
Analog Input(s)3 Inputs (0 - 10 VDC / -10 - 10 VDC / 4 - 20 mA)
Analog Output(s)1 Output (0 - 10 VDC), 1 Output (4 - 20 mA)
Control Input(s)1 Input (Motor Thermister), 8 Inputs (NPN)
Control Output(s)1 Output (Relay), 5 Outputs (NPN)
Integrated EPM Module:No
Integrated Keypad:Yes
Integrated Fwd / Rev Switch:No
Integrated Speed Pot:No
Integrated Disconnect:No
Integrated Brake Chopper:No
Integrated Communications:Modbus RTU (RS-485)
Learn MoreYou can hover your mouse over highlighted product specs to learn more.

Description

Estimated reading time: 11 minutes

Introduction: Why Choose Hitachi SJ700 Variable Frequency Drives VFDs?

When selecting a solution for industrial motor control, the Hitachi SJ700 variable frequency drives VFDs stand out for their exceptional performance and reliability. These drives are engineered to provide precise speed and torque control for a wide array of demanding applications, from complex machinery to simple fan and pump systems. Furthermore, the SJ700 series is built upon a legacy of robust design, ensuring long-term dependability in challenging industrial environments. According to Variable Frequency Drives, the advanced control features of drives like the Hitachi SJ700 are critical for achieving high performance in both open and closed-loop systems, making them a top choice for engineers and facility managers.

Hitachi SJ700 VFD: High Torque with Sensorless Vector

Delving deeper, the Hitachi SJ700 VFD incorporates powerful features such as Sensorless Vector Control (SLV), which delivers impressive torque even at low speeds. For instance, this AC motor drive SJ700 can achieve high starting torque without needing feedback from a motor encoder, simplifying system design and reducing costs. This performance is enhanced by a higher internal calculation speed, which, as noted by automatedpt.com, significantly improves current response and helps prevent nuisance trips during rapid acceleration. In addition, its impressive overload capacities, such as 150% for 60 seconds as detailed by another automatedpt.com document, ensure the drive can handle sudden load changes without faltering.

Ultimately, the versatility of the SJ700 inverter drive makes it an invaluable asset across numerous industries. Its advanced capabilities are not compromised by complexity; in fact, Hitachi has focused on user-friendly operation. With simplified programming and complimentary software, as highlighted by hitachiacdrive.com, technicians can quickly configure the drive for optimal performance. This combination of power, precision, and accessibility makes the Hitachi variable speed drive a strategic investment for improving process control, increasing energy efficiency, and minimizing downtime. Consequently, it provides a robust platform for any modern industrial motor control system.

Safe Installation and Wiring Best Practices

Safe and effective integration of Hitachi SJ700 variable frequency drives VFDs begins with strict adherence to established safety protocols and proper physical placement. Before any work commences, technicians must follow all Lockout/Tagout (LOTO) procedures to ensure the equipment is fully de-energized, complying with NFPA 70E standards. The mounting location is also critical; it must provide adequate ventilation and be shielded from excessive moisture, dust, and vibration. For instance, selecting an appropriate enclosure, such as an optional NEMA 1 kit mentioned by automatedpt.com, is essential for protecting the drive in various industrial environments.

Proper wiring is equally crucial for the performance and safety of any SJ700 inverter drive. You must separate high-voltage power cables from low-voltage control wiring to prevent electromagnetic interference (EMI), which can disrupt drive operation. Furthermore, all grounding connections must comply with National Electrical Code (NEC) requirements to ensure a solid path to earth, minimizing electrical noise and enhancing safety. As detailed by manualmachine.com, using shielded, twisted-pair cables for the drive’s programmable input terminals is a best practice to maintain signal integrity.

A clear image of the Hitachi SJ700 variable frequency drives VFDs unit mounted inside an industrial motor control panel.

The Hitachi SJ700 series offers robust performance and advanced features for a wide range of industrial applications, making it a top choice for efficient motor control.

Finally, managing the thermal environment is fundamental to the longevity of the Hitachi variable speed drive. The SJ700 generates significant heat during operation, which must be dissipated effectively to avoid overheating and premature component failure. Consequently, installers must respect the minimum clearance requirements specified in the technical manual to ensure unobstructed airflow. Some models include features for fan speed control to optimize cooling, as noted by Hitachi SJ700/L700 Drives. In other words, failing to provide proper ventilation can lead to nuisance trips and significantly reduce the operational lifespan of the drive.

Essential Programming for Your Hitachi SJ700 VFD

Proper Hitachi VFD programming is fundamental to unlocking the full potential of your hitachi sj700 variable frequency drives vfds. While the SJ700 is packed with advanced functions, setting up basic operational parameters is a streamlined process. Hitachi has notably simplified the user experience, providing intuitive interfaces and complimentary software to facilitate configuration, according to Hitachi SJ700 Service Manual. Consequently, even technicians new to the platform can quickly establish primary motor control for a wide range of applications. This initial setup forms the bedrock for more complex, performance-tuning adjustments later on.

To begin, you must accurately input the motor's nameplate data, including voltage, full load amps (FLA), frequency, and RPM. Following this, setting the acceleration and deceleration times is critical for smooth operation and load management, a process detailed in the VFD's instruction manual from manualmachine.com. Another essential step involves selecting the appropriate Volt/Hertz (V/F) pattern to match the load type. For instance, variable torque applications like pumps and fans require a different V/F curve than constant torque applications like conveyors, as outlined in technical documentation on manualmachine.com. Getting these core parameters right ensures both efficiency and equipment longevity.

Beyond basic motor data, programming the drive's logic is essential for system integration. The AC motor drive SJ700 features a bank of intelligent input terminals that can be assigned to over 100 different functions. For example, as noted by manualmachine.com, you can program specific terminals for start/stop commands, speed selection, or external fault resets. In other words, this flexibility allows the drive to be tailored precisely to the machine's control scheme. Ultimately, accurate programming leverages the VFD's higher internal calculation speed, which improves stability and helps prevent trips during demanding acceleration and deceleration ramps, a key performance feature highlighted by automatedpt.com.

Advanced Features for Peak Motor Efficiency

The Hitachi SJ700 variable frequency drives VFDs offer a suite of advanced features that extend far beyond simple motor speed adjustments. These drives leverage a powerful DSP for enhanced performance, including Sensorless Vector Control (SLV) which provides remarkable torque control even at low speeds. According to Variable Frequency Drives, this high level of control is essential for demanding industrial applications. Consequently, operators can achieve precise motor regulation and significantly improve overall system efficiency without the need for costly external feedback devices.

A technician demonstrates safe installation best practices for Hitachi SJ700 variable frequency drives VFDs, carefully wir...

Proper wiring and adherence to safety protocols are critical for the reliable and safe operation of any Hitachi SJ700 VFD installation.

Furthermore, the SJ700 inverter drive is engineered for stability and uptime. Its higher internal calculation speed dramatically improves current response, which in turn helps to prevent nuisance trips during rapid acceleration or deceleration, as noted by automatedpt.com. This AC motor drive SJ700 also includes an auto-tuning function that simplifies setup and optimizes motor parameters for peak performance. In other words, these intelligent features work together to ensure the drive operates reliably while maximizing energy savings and protecting connected equipment from electrical stress.

For applications requiring customized logic, the Hitachi VFD programming includes a built-in EzSQ (Easy Sequence) function, allowing users to create tailored programs directly on the drive. This internal PLC-like capability can eliminate the need for an external controller, thereby reducing system complexity and cost. As highlighted by Hitachi SJ700B AC Drive, Hitachi provides complimentary software to simplify this process. Moreover, features such as basic torque control in sensorless mode and slow creep speed offer granular control for positioning tasks, as detailed in documentation from Hitachi SJ700 Series Drives, making the SJ700 a highly adaptable solution for complex automation.

Integrating the Hitachi SJ700 with Industrial Control Systems

Seamlessly connecting a Hitachi SJ700 VFD with broader industrial control systems like PLCs or SCADA platforms is essential for creating a cohesive and responsive automation environment. This AC motor drive SJ700 is designed for easy integration, featuring built-in Modbus RTU communication for straightforward serial networking right out of the box. In addition, for facilities that utilize other industrial protocols, the drive’s functionality can be expanded with optional communication cards. According to Hitachi SJ700 Drives, this allows for versatile connectivity with networks such as DeviceNet and PROFIBUS-DP, ensuring compatibility in diverse operational settings.

Beyond network protocols, the Hitachi variable speed drive provides robust hardwired control capabilities through its versatile I/O. The unit includes a suite of programmable digital and analog inputs that can be configured for a wide range of functions, including start/stop commands, speed references, and multi-step speed selection. Furthermore, the instruction manual from Hitachi SJ700 Series highlights these intelligent input terminals, which empower engineers to tailor the drive’s response to external signals. Similarly, its intelligent output terminals, which include relay and transistor outputs as detailed by Hitachi SJ700 Series Manual, can signal drive status, fault conditions, or speed attainment back to the central controller.

Ultimately, this combination of flexible communication and configurable I/O allows the SJ700 inverter drive to become a fully integrated component of a plant-wide control strategy. As a result, operators gain enhanced visibility and control over motor operations, leading to improved process efficiency and simplified troubleshooting. This high level of integration is a key aspect of the drive's performance capabilities, a feature noted by industry publications like Variable Frequency Drives. Proper integration facilitates the collection of valuable diagnostic data, which is crucial for implementing predictive maintenance schedules and minimizing operational downtime.

A Practical Guide to Troubleshooting Hitachi SJ700 VFDs

A technician programming the essential parameters on the control panel of the hitachi sj700 variable frequency drives vfds.

Properly setting the programming parameters on your Hitachi SJ700 inverter drive is crucial for unlocking optimal performance and motor control efficiency.

Before attempting any SJ700 drive troubleshooting, it is imperative to follow all standard safety protocols, including NFPA 70E guidelines and proper Lockout/Tagout (LOTO) procedures. A systematic approach to diagnosing Hitachi SJ700 variable frequency drives VFDs begins with understanding the unit’s comprehensive array of built-in protective functions, which are designed to signal specific operational faults. According to documentation from Hitachi SJ700 Series Instruction Manual, these functions can detect everything from overcurrent and overvoltage to EEPROM errors, providing a clear starting point for any diagnostic effort. Consequently, identifying the specific fault code displayed on the operator panel is the most critical first step toward a quick resolution.

Common Hitachi SJ700 VFD Faults & Solutions

Common trip codes often point directly to the root cause of an issue, saving significant diagnostic time. For instance, an overcurrent fault during startup may indicate that acceleration settings are too aggressive for the connected load, a problem that can be adjusted within the drive's parameters as detailed in the user manual from Hitachi SJ700 Series Instruction Manual. On the other hand, an overvoltage fault during deceleration might suggest the need for a dynamic braking resistor. Other frequent issues can include overheating, often caused by a malfunctioning cooling fan or blocked airways, and undervoltage, which typically points to problems with the incoming power supply. The drive includes features like fan speed control to help mitigate some of these thermal issues, as noted by Hitachi SJ700/L700 Drives.

If the drive does not display a specific error code, technicians should then perform a series of fundamental checks. Initially, verify that the incoming AC voltage is stable and within the drive's specified range. After that, carefully inspect all power and control wiring for secure connections, paying close attention to the programmable intelligent input terminals that control key functions. As described in its technical documentation, the Hitachi SJ700 VFD relies on these inputs for critical commands, and a loose connection can cause erratic behavior. Checking for proper grounding is another essential step, as electrical noise can interfere with the sensitive control logic of the AC motor drive SJ700. For reference, Hitachi SJ700 Series Manual provides detailed diagrams of these terminal functions.

Preventive Maintenance for Your Hitachi Frequency Converter

Proactive preventive maintenance is essential for ensuring the longevity and reliable operation of your Hitachi frequency converter. Regularly servicing your SJ700 inverter drive helps prevent unexpected downtime and costly emergency repairs. Fortunately, Hitachi designed these units with serviceability in mind; for instance, key components like cooling fans and capacitors can be easily monitored and replaced when needed. According to documentation from Hitachi SJ700-L700 Drives, a structured maintenance schedule is the best defense against premature VFD failure.

A regular inspection schedule should begin with the drive's environment. First, ensure the VFD is free from dust, moisture, and corrosive contaminants, as these can lead to short circuits or component degradation. It's also critical to verify that all terminal connections are secure, since vibrations can cause them to loosen over time. Furthermore, check that the cooling fans are functioning correctly to maintain proper airflow. As noted by Hitachi SJ700 L700 Drives, the Hitachi SJ700 series includes features like fan speed control, but physical blockages can still lead to overheating. Always perform these checks after following strict Lockout/Tagout (LOTO) procedures.

Beyond routine inspections, it is important to plan for the replacement of components with a limited lifespan. Specifically, electrolytic capacitors in the DC bus and the cooling fans are consumable parts that degrade over several years of operation. Neglecting them can result in voltage regulation issues or thermal trips. The drive's internal diagnostics can help monitor component health, aligning with protective functions detailed in the official manual from Hitachi SJ700 Series Manual. By proactively replacing these items based on the manufacturer's recommended service intervals, you can significantly enhance the reliability of your AC motor drive SJ700.

Conclusion: Unlocking Long-term Performance and Savings

Ultimately, the hitachi sj700 variable frequency drives vfds represent more than just a component; they are a cornerstone of modern industrial motor control. Throughout this guide, we have explored their robust capabilities, from safe installation and essential programming to advanced features that maximize motor efficiency. By leveraging its sophisticated Sensorless Vector Control, which provides outstanding torque and speed regulation even at low frequencies, facilities can achieve unparalleled precision, as noted by sources like Variable Frequency Drives. This level of control is crucial in applications from CNC machining to large-scale HVAC systems, ensuring both reliability and operational excellence; mastering this technology is a critical step toward optimizing your entire production output.

In conclusion, the decision to implement an AC motor drive SJ700 is a strategic investment in long-term performance and financial savings. The drive's simplified programming, detailed by Hitachi SJ700B AC Drive, reduces setup time, while its impressive overload capacity ensures durability under demanding conditions, a key specification found on Hitachi SJ700 Series Drives. Actionable advice for managers includes auditing motor run-times and load profiles to quantify potential energy reductions, which often exceed initial projections. Consequently, proper application and maintenance of the Hitachi SJ700 VFD not only enhance system control but also significantly lower energy consumption, reduce mechanical stress on equipment, and cut utility demand charges, delivering a powerful return on investment for years to come.

Read The Full Hitachi SJ700 Variable Frequency Drives VFDs Research:

The Full Hitachi SJ700 Variable Frequency Drives VFDs ResearchDownload

SJ700 Series Technical Manuals

Product Manual

  • Installation And Operation Manual NB206XA (8.29 MB)
  • Drive Service Manual NTS204X (7.79 MB)
